Product Summary
The EP1C3T144C8N is a Cyclone FPGA. It contains a two-dimensional row- and column-based architecture to implement custom logic. Column and row interconnects of varying speeds provide signal interconnects between LABs and embedded memory blocks. The logic array consists of LABs, with 10 LEs in each LAB. An LE is a small unit of logic providing efficient implementation of user logic functions.
Parametrics
EP1C3T144C8N absolute maximum ratings: (1)On the conditions of With respect to ground, VCCINT Supply voltage: min=-0.5V,max=2.4V; VCCIO: min=-0.5V,max=4.6V; (2)On the conditions of With respect to ground, VCCA Supply voltage: min=-0.5V,max=2.4V; (3)VI DC input voltage: min=-0.5V,max=4.6V; (4)IOUT DC output current, per pin: min=-25mA, max=25mA; (5)On the conditions of No bias, TSTG Storage temperature: min=-65℃, max=150℃; (6)On the conditions of Under bias, TAMB Ambient temperature: min=-65℃, max=135℃; (7)On the conditions of BGA packages under bias, TJ Junction temperature: max=135℃.
Features
EP1C3T144C8N features: (1)Up to 294,912 RAM bits (36,864 bytes); (2)Supports configuration through low-cost serial configuration device; (3)Support for LVTTL, LVCMOS, SSTL-2, and SSTL-3 I/O standards; (4)Support for 66- and 33-MHz, 64- and 32-bit PCI standard; (5)High-speed (640 Mbps) LVDS I/O support; (6)Low-speed (311 Mbps) LVDS I/O support; (7)311-Mbps RSDS I/O support; (8)Up to two PLLs per device provide clock multiplication and phase shifting.
Diagrams
