Product Summary

The CY7C133-35JI and CY7C143 are high-speed CMOS 2K by 16 dual-port static RAMs. Two ports are provided permitting independent access to any location in memory. The CY7C133-35JI can be utilized as either a stand-alone 16-bit dual-port static RAM or as a master dual-port RAM in conjunction with the CY7C133-35JI slave dual-port device in systems requiring 32-bit or greater word widths. It is the solution to applications requiring shared or buffered data, such as cache memory for DSP, bit-slice, or multiprocessor designs.

Parametrics

CY7C133-35JI absolute maximum ratings: (1)Storage Temperature: 65℃ to +150℃; (2)Ambient Temperature with Power Applied: 55℃ to +125℃; (3)Supply Voltage to Ground Potential (Pin 48 to Pin 24): -0.5V to +7.0V; (4)DC Voltage Applied to Outputs in High-Z State: -0.5V to +7.0V; (5)DC Input Voltage: -3.5V to +7.0V; (6)Output Current into Outputs (LOW): 20 mA; (7)Static Discharge Voltage: >2001V; (8)Latch-up Current: >200 mA.

Features

CY7C133-35JI features: (1)True dual-ported memory cells which allow simultaneous reads of the same memory location; (2)2K x 16 organization; (3)0.65-micron CMOS for optimum speed/power; (4)High-speed access: 25/35/55 ns; (5)Low operating power: ICC = 150 mA (typ.); (6)Fully asynchronous operation; (7)Master CY7C133 expands data bus width to 32 bits or more using slave CY7C143; (8)BUSY output flag on CY7C133; BUSY input flag on CY7C143; (9)Available in 68-pin PLCC.

Diagrams
